Super Single 17x9" Steel Rim – 6-Stud Fuso / Isuzu (Part No. 517072010)
Built tough for Australian conditions, the Super Single 17x9" steel rim is purpose-designed for Fuso and Isuzu 4x4 trucks with a 6-stud hub pattern. This rim converts dual rear wheels into a single wide-track setup, improving off-road capability, simplifying tyre rotations, and reducing weight.
Key Features:
·Fits 6-stud Fuso and Isuzu 4x4 truck platforms
·Converts rear duals to a single 17x9" rim
·Improves ground clearance, handling, and tyre access
·Constructed from high-strength steel for maximum durability
·DOT stamped for road compliance
Performance Certified:
·Tested in accordance with SAE J2530a
·2,300kg load rating per rim
·Withstood 35,000 revolutions at 450 r/min
·Survived a Dynamic Cornering Fatigue force of 12,657Nm
Valve Requirements:
Each rim requires:
·1 x high-pressure valve
·1 x 90-degree valve stem
We can supply these at $6.00 each — just let us know when ordering.
Specifications:
·Size: 17x9"
·Stud Pattern: 6-stud
·Material: Heavy-duty steel
·Part Number: 517072010
This rim is made for those who demand strength, reliability, and performance — whether you’re heading off-road or loading up for work.
