AAV4X4
SKU: 220198 1W+1WSPEC ORD
Order Item - This product may need to be assembled or ordered in depending on current stock. If components are available, it is usually ready within approximately 1-3 business days. We will contact you if there are any delays.
Complete AAV4x4 kinetic subframe and dual-water-tank package for compatible Isuzu NPS 75 Dual Cab vehicles, providing a combined 440 litres of onboard water capacity.
The package combines a special-order 150L front water tank with a 290L rear water tank, mounted with AAV4x4's kinetic subframe system and professionally installed with the required plumbing, electrical system, tank monitoring equipment and associated mounting hardware.
The water delivery system is configured to suit the customer's intended use rather than being restricted to a fixed pump-and-tap arrangement.
A typical installation uses a single pump and single outlet; however, the package pricing allows the system to be configured appropriately for the application.
Depending on requirements, the finished system may use independent pumps and outlets for the two tanks, a higher-capacity common pump supplying the water system, or a primary outlet with an additional auxiliary outlet positioned elsewhere on the camper or vehicle body.
The final pump, outlet and plumbing arrangement is confirmed with the customer as part of the build to suit how the onboard water system will actually be used.
The water tanks are incorporated into AAV4x4's kinetic subframe system, designed to provide a dedicated mounting structure between the Isuzu chassis and the tray, canopy or body installation.
The package includes the kinetic mounting hardware, spring and urethane mounting components required for the subframe installation.
Both water tanks are equipped with level senders and are monitored through the fitted in-cabin gauge system, allowing the driver to check the onboard water supply from inside the vehicle.
| Vehicle Application | Compatible Isuzu NPS 75 Dual Cab |
|---|---|
| Front Water Tank | 150L special-order water tank |
| Rear Water Tank | 290L |
| Total Water Capacity | 440L |
| Water Delivery | Configured to suit customer requirements |
| Tank Monitoring | In-cabin gauge with individual tank sender units |
| Installation | Professionally fitted by AAV4x4 |
This is a configurable fitted package. The final water pump, plumbing and outlet arrangement is confirmed with the customer before completion so the system can be configured around the intended use of the two water tanks.
The package price allows for the appropriate agreed water-delivery configuration rather than restricting the installation to a predetermined number of pumps or outlets.
