This Fuso FGB71 towbar package is supplied and fitted as a complete rear towing upgrade, including the heavy duty towbar assembly, removable tongue, 50mm tow ball, 7 pin flat trailer plug wiring and ECU distribution box.
The AAV4x4 FGB71 towbar is designed to suit Fuso FGB71 applications and allows a 37" spare tyre to remain mounted under the chassis in the original OEM position, within the chassis rails.
This package includes the towbar fitting kit, trailer wiring loom, CAN bus trailer adaptor, body plug wiring loom, 7 pin flat trailer connection, and towbar washers.
Product Details
-
Product: Fuso FGB71 Towbar 3500Kg Rated, ECU Box & 7 Pin Flat Trailer Plug Fitted
-
Towbar rating: 3500kg rated towbar, subject to vehicle GVM and compliance requirements
-
Tow ball: 50mm tow ball included
-
Trailer connection: 7 pin flat trailer plug
-
Electrical system: ECU distribution box and plug-in trailer wiring loom
-
Vehicle fitment: Fuso FGB71
What This Package Includes
- Fuso FGB71 heavy duty towbar assembly
- Removable towbar tongue
- 50mm tow ball
- Towbar fitting kit
- 7 pin flat trailer plug wiring
- Fuso ECU distribution box
- Plug-in no-solder trailer wiring loom kit
- Towbar compliance stickers
- Fitment labour
Kit Components
- Fuso FGB71 HD 3500/4500Kg Towbar, Towball & Fitting Kit - Qty 1
- Fuso FGB71 Towbar Electrics Only 7 Pin & ECU Box Plug-In No-Solder Loom Kit - Qty 1
- Fuso / Isuzu Towbar Loom 7 Pin Flat Including Module - Qty 1
- Fuso / Isuzu Towbar Loom 7 Pin Flat, Complete With Module - Qty 1
- AAV CAN Bus Trailer Adaptor Converter 12/24V - Qty 1
- Fuso Body Plug Wiring Loom - Qty 1
- Towbar Washers - Qty 2
Towing Capacity Guide
-
GVM 5000kg or under: 3500kg towing capacity
-
GVM 6000kg: 3089kg towing capacity
-
GVM 6500kg: 2972kg towing capacity
-
GVM 7000kg: 2878kg towing capacity
-
GVM 7500kg: 2801kg towing capacity
Key Features
- Designed for Fuso FGB71 applications
- Allows a 37" spare tyre to remain under the chassis in the OEM position
- Includes 50mm tow ball and removable tongue
- Includes 7 pin flat trailer plug wiring
- Includes ECU distribution box and CAN bus trailer adaptor
- Plug-in no-solder loom kit for a cleaner installation
- Supplied and fitted as a complete towbar package
Common Uses
- Fuso FGB71 towing upgrades
- Trailer and equipment towing
- Caravan and camper trailer towing
- Touring and work vehicle builds requiring a fitted towbar and trailer electrics
- Vehicles needing towbar fitment while retaining the under-chassis spare tyre position
Optional Upgrades
- Optional Super Duty adjustable hitch tongue rated to 4500kg GTW and compliant with ADR62/02
- Optional 16 stage height adjustment hitch setup
- Optional rear winch carrier
Compliance Notes
- Actual towing capacity depends on the host vehicle GVM.
- Under NHVR Vehicle Standards Guide VSG-16, towing capacity with a 50mm ball varies depending on vehicle GVM.
- If the vehicle is over 4495kg GVM, this towbar will require vehicle compliance at an additional cost.
- Final suitability must be confirmed against the vehicle, GVM, intended towing setup and compliance requirements.
Important: The listed towbar rating does not automatically mean every vehicle can tow 3500kg. Actual towing capacity depends on the vehicle GVM, towing equipment, compliance requirements and final vehicle configuration.
